Remove usages of deprecated setSystemUiVisibility() #29493

camsim99 · 2021-11-03T00:59:14Z

Removes uses of setSystemUiVisibility() in the engine.

Pre-launch Checklist

I read the [Contributor Guide] and followed the process outlined there for submitting PRs.
I read the [Tree Hygiene] wiki page, which explains my responsibilities.
I read and followed the [Flutter Style Guide] and the [C++, Objective-C, Java style guides].
I listed at least one issue that this PR fixes in the description above.
I added new tests to check the change I am making or feature I am adding, or Hixie said the PR is test-exempt. See [testing the engine] for instructions on
writing and running engine tests.
I updated/added relevant documentation (doc comments with ///).
I signed the [CLA].
All existing and new tests are passing.

shell/platform/android/io/flutter/plugin/platform/PlatformPlugin.java

wytesk133 · 2021-11-09T04:59:52Z

shell/platform/android/io/flutter/app/FlutterActivityDelegate.java

      window.setStatusBarColor(0x40000000);
-      window.getDecorView().setSystemUiVisibility(PlatformPlugin.DEFAULT_SYSTEM_UI);
+      if (Build.VERSION.SDK_INT >= 30) {
+        window.setDecorFitsSystemWindows(false);


Should we use https://developer.android.com/reference/androidx/core/view/WindowCompat instead?

Is there an advantage of using this? The window.setDecorFitsSystemWindows(boolean) behavior seems to mirror that of the windowCompat.setDecorFitsSystemWindows(window, boolean) behavior.

Edit: I do see that the windowCompat version is not compatible with the deprecated flags so I will try to use that.

{ClassName}Compat is part of the AndroidX library. It provides a compatibility layer that handles all the inconsistencies between each version behind-the-scene.

Example 1

Example 2

Since the implementation details are abstracted from us, we can worry less about adding if statements for specific versions on our side and focus more on the feature work. In this case, we should try to migrate the deprecated code to use WindowCompat and WindowInsetsControllerCompat instead.

Piinks · 2021-12-01T17:34:45Z

shell/platform/android/io/flutter/plugin/platform/PlatformPlugin.java

+            View.SYSTEM_UI_FLAG_LAYOUT_STABLE
+                | View.SYSTEM_UI_FLAG_LAYOUT_HIDE_NAVIGATION
+                | View.SYSTEM_UI_FLAG_LAYOUT_FULLSCREEN
+                | View.SYSTEM_UI_FLAG_HIDE_NAVIGATION
+                | View.SYSTEM_UI_FLAG_FULLSCREEN;


These flags are also deprecated aren't they? Or are these going to be migrated in a separate change?

The new API is backwards compatible, so I will take care of these in this PR as well!

blasten · 2022-01-13T00:15:45Z

shell/platform/android/io/flutter/plugin/platform/PlatformPlugin.java

+    setSystemChromeEnabledSystemUIMode(currentSystemUiMode);
+
+    if (currentOverlays != null) {
+      setSystemChromeEnabledSystemUIOverlays(currentOverlays);


setSystemChromeEnabledSystemUIOverlays sets currentOverlays.

Is what situation updateSystemUiOverlays needs to call setSystemChromeEnabledSystemUIOverlays again with the same value?

If someone decides to make a call to setSystemChromeEnabledSystemUIMode after updateSystemUiOverlays is called to change the systemUiMode, this could possibly hide some of the system bars, so then calling updateSystemUiOverlays would show those system bars again.

right, but wouldn't an external call to setSystemChromeEnabledSystemUIMode set a new currentSystemUiMode , thus making updateSystemUiOverlays() call setSystemChromeEnabledSystemUIMode(currentSystemUiMode) with the same value?

Oh, I see what you mean. In that case, if currentOverlays isn't null, then there's no need to make the call to setSystemChromeEnabledSystemUIMode.

blasten

LGTM! - I will defer to @Piinks for final review :)

Piinks

blasten · 2022-01-13T19:05:50Z

shell/platform/android/io/flutter/plugin/platform/PlatformPlugin.java

+    } else {
+      if (currentTheme != null) {


nit else/if -> else if (currentTheme != null)) {

…engine#29493)

wytesk133 · 2022-01-14T09:27:45Z

shell/platform/android/io/flutter/app/FlutterActivityDelegate.java

      window.addFlags(LayoutParams.FLAG_DRAWS_SYSTEM_BAR_BACKGROUNDS);
      window.setStatusBarColor(0x40000000);
-      window.getDecorView().setSystemUiVisibility(PlatformPlugin.DEFAULT_SYSTEM_UI);
+      WindowCompat.setDecorFitsSystemWindows(window, false);


This line means edge-to-edge mode will become the default mode (related to flutter/flutter#86248 ?). It would be great if we can eventually land this, but do note that it will be a breaking change for apps that don't handle paddings/safe area properly. My team had to manually apply non-trivial fixes (e.g. cl/397106186 and cl/397283284) before enabling this.

wytesk133 · 2022-01-14T09:40:59Z

shell/platform/android/io/flutter/plugin/platform/PlatformPlugin.java

+    if (systemUiMode == PlatformChannel.SystemUiMode.LEAN_BACK) {
      // LEAN BACK
-      // Available starting at SDK 16
+      // Available starting at SDK 20, due to the backwards compatibility provided by the


It would be great if we can eventually migrate from the deprecated APIs to use AndroidX's compat libraries, but according to https://docs.flutter.dev/development/tools/sdk/release-notes/supported-platforms we are also supporting API 19. Seems like everything here and below will require API 20+. We might need to rethink a bit on the supported modes and the default mode (especially if edge-to-edge, which works best on API 29+, is going to be the new default).
