[SPARK-36290][SQL] Pull out complex join condition

[wangyum]

What changes were proposed in this pull request?

Similar to PullOutGroupingExpressions. This PR adds a new rule(PullOutComplexJoinCondition) to pull out complex join condition.

Why are the changes needed?

Pull out complex join condition has following advantage:

1. Reduce the number of complex expression evaluations from 3 to 2 times if it is SortMergeJoin..
2. Infer more additional filters, sometimes can avoid data skew. For example: [SPARK-31809][SQL] Infer IsNotNull from some special equality join keys #28642
3. Avoid other rules also need to handle complex condition. For example: https://github.com/apache/spark/blob/dee7396204e2f6e7346e220867953fc74cd4253d/sql/catalyst/src/main/scala/org/apache/spark/sql/catalyst/optimizer/PushPartialAggregationThroughJoin.scala#L325-L327

For example:

CREATE TABLE t1 (item_id BIGINT, event_type STRING, dt STRING) USING parquet PARTITIONED BY (dt);
CREATE TABLE t2 (item_id BIGINT, cal_dt DATE) using parquet;
set spark.sql.autoBroadcastJoinThreshold=-1;

SELECT a.item_id,
       a.event_type
FROM   t1 a
       INNER JOIN (SELECT DISTINCT cal_dt,
                                   item_id
                   FROM   t2) b
               ON a.item_id = b.item_id
                  AND To_date(a.dt, 'yyyyMMdd') = b.cal_dt
WHERE To_date(a.dt, 'yyyyMMdd') = date '2022-10-01';

Before this PR:

== Physical Plan ==
AdaptiveSparkPlan isFinalPlan=false
+- Project [item_id#28L, event_type#29]
   +- SortMergeJoin [cast(gettimestamp(dt#30, yyyyMMdd, TimestampType, Some(America/Los_Angeles), false) as date), item_id#28L], [cal_dt#32, item_id#31L], Inner
      :- Sort [cast(gettimestamp(dt#30, yyyyMMdd, TimestampType, Some(America/Los_Angeles), false) as date) ASC NULLS FIRST, item_id#28L ASC NULLS FIRST], false, 0
      :  +- Exchange hashpartitioning(cast(gettimestamp(dt#30, yyyyMMdd, TimestampType, Some(America/Los_Angeles), false) as date), item_id#28L, 5), ENSURE_REQUIREMENTS, [plan_id=78]
      :     +- Filter isnotnull(item_id#28L)
      :        +- FileScan parquet spark_catalog.default.t1[item_id#28L,event_type#29,dt#30]
      +- Sort [cal_dt#32 ASC NULLS FIRST, item_id#31L ASC NULLS FIRST], false, 0
         +- HashAggregate(keys=[cal_dt#32, item_id#31L], functions=[])
            +- Exchange hashpartitioning(cal_dt#32, item_id#31L, 5), ENSURE_REQUIREMENTS, [plan_id=74]
               +- HashAggregate(keys=[cal_dt#32, item_id#31L], functions=[])
                  +- Filter (isnotnull(item_id#31L) AND isnotnull(cal_dt#32))
                     +- FileScan parquet spark_catalog.default.t2[item_id#31L,cal_dt#32]

After this PR:

== Physical Plan ==
AdaptiveSparkPlan isFinalPlan=false
+- Project [item_id#28L, event_type#29]
   +- SortMergeJoin [CAST(gettimestamp(a.#37, item_id#28L], [cal_dt#32, item_id#31L], Inner
      :- Sort [CAST(gettimestamp(a.#37 ASC NULLS FIRST, item_id#28L ASC NULLS FIRST], false, 0
      :  +- Exchange hashpartitioning(CAST(gettimestamp(a.#37, item_id#28L, 5), ENSURE_REQUIREMENTS, [plan_id=78]
      :     +- Project [item_id#28L, event_type#29, cast(gettimestamp(dt#30, yyyyMMdd, TimestampType, Some(America/Los_Angeles), false) as date) AS CAST(gettimestamp(a.#37]
      :        +- Filter isnotnull(item_id#28L)
      :           +- FileScan parquet spark_catalog.default.t1[item_id#28L,event_type#29,dt#30]
      +- Sort [cal_dt#32 ASC NULLS FIRST, item_id#31L ASC NULLS FIRST], false, 0
         +- HashAggregate(keys=[cal_dt#32, item_id#31L], functions=[])
            +- Exchange hashpartitioning(cal_dt#32, item_id#31L, 5), ENSURE_REQUIREMENTS, [plan_id=74]
               +- HashAggregate(keys=[cal_dt#32, item_id#31L], functions=[])
                  +- Filter (((cal_dt#32 = 2022-10-01) AND isnotnull(item_id#31L)) AND isnotnull(cal_dt#32))
                     +- FileScan parquet spark_catalog.default.t2[item_id#31L,cal_dt#32]

Performance evaluation:

Spark	Job Duration(min)
Vanilla	38
Pull out complex join condition and disable spark.sql.constraintPropagation.enabled	3.6
Pull out complex join condition and enable spark.sql.constraintPropagation.enabled	1.8

Does this PR introduce any user-facing change?

No.

How was this patch tested?

Unit test.

[wangyum]

Case from production:

Before	After
