Redis Server Implementation in Java

This project is a Java implementation of a Redis server, built as part of the Codecrafters "Build Your Own Redis" challenge. It demonstrates key concepts in building distributed systems, network protocols, and in-memory databases.

📌 What This Project Does

This Redis implementation covers the fundamental components of a modern in-memory data store:

• RESP Protocol: Complete implementation of the Redis Serialization Protocol for client-server communication.
• Multi-threaded Server: Uses Java's virtual threads to handle concurrent client connections efficiently.
• Data Structures: Support for strings, lists, sorted sets, and streams with Redis-compatible operations.
• Persistence: RDB file loading and parsing for data durability.
• Replication: Master-slave replication with automatic synchronization.
• Pub/Sub Messaging: Publisher-subscriber pattern for real-time messaging.
• Transactions: ACID-compliant transaction support with MULTI/EXEC/DISCARD.
• Expiration: Time-based key expiration with automatic cleanup.

✨ Key Features

Core Data Operations

• String Operations: GET, SET, INCR with optional expiration times
• Configuration: CONFIG GET for server configuration retrieval
• Key Management: KEYS, TYPE commands for key introspection
• Server Info: INFO, PING, ECHO for server status and diagnostics

Advanced Data Structures

Lists

• Push Operations: LPUSH, RPUSH for adding elements
• Pop Operations: LPOP, BLPOP (blocking) for removing elements
• Range Operations: LRANGE for retrieving ranges of elements
• Metadata: LLEN for list length information

Sorted Sets

• Insertion: ZADD for adding scored members
• Ranking: ZRANK for member position queries
• Range Queries: ZRANGE for retrieving members by rank
• Metadata: ZCARD, ZSCORE for set information
• Removal: ZREM for removing members

Streams

• Stream Creation: XADD for adding entries with unique IDs
• Range Queries: XRANGE for retrieving entries by ID range
• Blocking Reads: XREAD with optional blocking for real-time consumption

Messaging & Communication

• Pub/Sub: SUBSCRIBE, UNSUBSCRIBE, PUBLISH for message broadcasting
• Transactions: MULTI, EXEC, DISCARD for atomic command execution
• Replication: PSYNC, REPLCONF, WAIT for master-slave synchronization

System Features

• RDB Loading: Automatic loading of Redis Database files on startup
• Key Expiration: Automatic cleanup of expired keys with millisecond precision
• Blocking Operations: Non-blocking server design with blocking client operations
• Error Handling: Comprehensive error reporting following Redis conventions

🏗️ Architecture Overview

Network Layer

The server uses Java's virtual threads to handle client connections concurrently. Each client connection runs in its own virtual thread, allowing for high concurrency with minimal resource overhead.

Command Processing

Commands are processed using the Command pattern, with each Redis command implemented as a separate class that implements the Command interface.

Storage Engine

The storage layer provides a thread-safe, concurrent map with support for:

• Key-value storage with expiration
• Type-specific operations (lists, sorted sets, streams)
• Atomic operations and transactions

RESP Protocol

Complete implementation of the Redis Serialization Protocol (RESP) for:

• Parsing client requests
• Serializing server responses
• Handling different data types (strings, arrays, integers, errors)

🔍 How It Works Internally

The Redis server processes client requests through several stages:

1. Connection Handling: When a client connects, the server creates a new Client instance running in a virtual thread.

2. Request Parsing: The Deserializer class parses incoming RESP-formatted requests into RValue objects representing the command and arguments.

3. Command Routing: The Redis class routes parsed commands to the appropriate Command implementation based on the command name.

4. Command Execution: Each command class implements the Command interface with an execute method that:

   • Validates arguments
   • Performs the requested operation
   • Returns a properly formatted response

5. Response Serialization: Results are serialized back to RESP format and sent to the client.

6. State Management: The server maintains:

   • Storage: Thread-safe key-value store with expiration
   • Replication: List of connected replica servers
   • Pub/Sub: Channel subscriptions and message routing
   • Transactions: Queued commands for atomic execution

⚙️ How to Set Up and Run

Prerequisites

• Java 21 or later (for virtual thread support)
• Maven 3.6+ for dependency management

Installation

1. Clone the repository:

   git clone https://github.com/Md-Talim/codecrafters-redis-java.git
   cd codecrafters-redis-java

2. Build the project:

   mvn compile

Running the Server

Basic Usage:

./your_program.sh

With Configuration Options:

./your_program.sh --port 6380 --dir /tmp --dbfilename dump.rdb

As a Replica Server:

./your_program.sh --port 6380 --replicaof "localhost 6379"

Available Configuration Options:

Option	Description	Default	Example
--port	Port number for the server	6379	--port 6380
--dir	Directory for RDB files	-	--dir /tmp
--dbfilename	RDB filename	-	--dbfilename dump.rdb
--replicaof	Master server for replication	-	--replicaof "localhost 6379"

Testing with Redis CLI

Once the server is running, you can connect using the standard Redis CLI:

redis-cli -p 6379

Example Usage

# Basic string operations
127.0.0.1:6379> SET mykey "Hello, Redis!"
OK
127.0.0.1:6379> GET mykey
"Hello, Redis!"

# List operations
127.0.0.1:6379> LPUSH mylist "world" "hello"
(integer) 2
127.0.0.1:6379> LRANGE mylist 0 -1
1) "hello"
2) "world"

# Sorted set operations
127.0.0.1:6379> ZADD myset 1 "one" 2 "two" 3 "three"
(integer) 3
127.0.0.1:6379> ZRANGE myset 0 -1
1) "one"
2) "two"
3) "three"

# Stream operations
127.0.0.1:6379> XADD mystream * field1 value1 field2 value2
"1234567890-0"
127.0.0.1:6379> XRANGE mystream - +
1) 1) "1234567890-0"
   2) 1) "field1"
      2) "value1"
      3) "field2"
      4) "value2"

# Pub/Sub messaging
127.0.0.1:6379> SUBSCRIBE news
Reading messages... (press Ctrl-C to quit)

# In another terminal:
127.0.0.1:6379> PUBLISH news "Hello subscribers!"
(integer) 1

# Transactions
127.0.0.1:6379> MULTI
OK
127.0.0.1:6379> SET key1 "value1"
QUEUED
127.0.0.1:6379> SET key2 "value2"
QUEUED
127.0.0.1:6379> EXEC
1) OK
2) OK

📁 Project Structure

redis-java/
├── src/main/java/redis/
│   ├── Main.java                    # Application entry point
│   ├── Redis.java                   # Core server orchestration
│   ├── client/                      # Client connection handling
│   │   ├── Client.java              # Individual client management
│   │   └── ReplicaClient.java       # Replica server client
│   ├── command/                     # Redis command implementations
│   │   ├── Command.java             # Command interface
│   │   ├── CommandRegistry.java     # Command registration
│   │   ├── core/                    # Basic commands (GET, SET, etc.)
│   │   ├── list/                    # List operations (LPUSH, RPUSH, etc.)
│   │   ├── sortedset/              # Sorted set operations (ZADD, ZRANGE, etc.)
│   │   ├── stream/                 # Stream operations (XADD, XREAD, etc.)
│   │   ├── pubsub/                 # Pub/Sub commands
│   │   ├── replication/            # Replication commands
│   │   └── transaction/            # Transaction commands
│   ├── configuration/              # Server configuration management
│   ├── pubsub/                     # Pub/Sub message handling
│   ├── rdb/                        # RDB file parsing and loading
│   ├── resp/                       # RESP protocol implementation
│   ├── store/                      # Storage engine and data structures
│   ├── stream/                     # Stream data structure implementation
│   └── util/                       # Utility classes (tracked I/O streams)
├── your_program.sh                 # Server startup script
└── README.md                       # This file

🎯 Implemented Redis Commands

String Commands

• GET key - Get value of key
• SET key value [PX milliseconds] - Set key to value with optional expiration
• INCR key - Increment integer value of key

List Commands

• LPUSH key element... - Prepend elements to list
• RPUSH key element... - Append elements to list
• LPOP key [count] - Remove and return first element(s)
• BLPOP key timeout - Blocking version of LPOP
• LRANGE key start stop - Get range of elements
• LLEN key - Get list length

Sorted Set Commands

• ZADD key score member - Add member with score
• ZRANGE key start stop - Get members by rank range
• ZRANK key member - Get rank of member
• ZCARD key - Get number of members
• ZSCORE key member - Get score of member
• ZREM key member - Remove member

Stream Commands

• XADD key id field value... - Add entry to stream
• XRANGE key start end - Get entries by ID range
• XREAD [BLOCK milliseconds] STREAMS key... id... - Read from streams

Pub/Sub Commands

• SUBSCRIBE channel... - Subscribe to channels
• UNSUBSCRIBE [channel...] - Unsubscribe from channels
• PUBLISH channel message - Publish message to channel

Transaction Commands

• MULTI - Start transaction
• EXEC - Execute queued commands
• DISCARD - Discard queued commands

Server Commands

• PING - Test server connectivity
• ECHO message - Echo message back
• CONFIG GET parameter - Get configuration parameter
• INFO - Get server information
• KEYS pattern - Get keys matching pattern
• TYPE key - Get type of key

Replication Commands

• PSYNC replicationid offset - Synchronize with master
• REPLCONF option value - Configure replication
• WAIT numreplicas timeout - Wait for replica acknowledgments

💡 Technical Challenges & Solutions

Concurrency & Thread Safety

• Challenge: Handle thousands of concurrent connections efficiently.
• Solution: Used Java 21's virtual threads for lightweight concurrency and ConcurrentHashMap for thread-safe storage.

RESP Protocol Implementation

• Challenge: Parse and serialize Redis protocol messages correctly.
• Solution: Implemented a robust Deserializer and RValue hierarchy with proper serialization methods.

Blocking Operations

• Challenge: Implement blocking commands like BLPOP without blocking the server.
• Solution: Used ReentrantLock with Condition variables for efficient waiting and notification.

Memory Management

• Challenge: Automatic expiration of keys without memory leaks.
• Solution: Implemented lazy expiration checking during key access with CacheEntry wrapper objects.

Replication Consistency

• Challenge: Keep replica servers synchronized with master state.
• Solution: Implemented command propagation with offset tracking and acknowledgment waiting. This was one of the most complex parts of the project, and I benefited from studying Enzo Caceres' implementation to understand the intricacies of the PSYNC protocol and replica management.

Stream Data Structure

• Challenge: Implement Redis streams with unique ID generation and range queries.
• Solution: Created custom Stream class with proper ID comparison and concurrent read/write operations.

🚀 Performance Characteristics

• Throughput: Capable of handling thousands of concurrent connections using virtual threads
• Memory: Efficient memory usage with lazy expiration and concurrent data structures
• Latency: Low-latency responses through optimized command routing and minimal allocations
• Scalability: Master-slave replication support for horizontal scaling

🧪 Testing

The implementation has been tested against the CodeCrafters test suite, which validates:

• Protocol compliance with official Redis specification
• Correct behavior for all implemented commands
• Proper error handling and edge cases
• Replication functionality
• Transaction atomicity
• Pub/Sub message delivery

🙏 Acknowledgments

• This project implements the Redis server as described in the CodeCrafters "Build Your Own Redis" challenge
• Thanks to the Redis team for creating such an elegant and well-documented protocol

📚 Learning Resources

• Redis Protocol Specification
• Redis Commands Reference
• CodeCrafters Redis Challenge
• Java Virtual Threads Documentation
